Detail PanBlast™ Heavy Duty Blast Cabinets – Model PB1000
PanBlast™ Heavy Duty Suction Blast Cabinets are highly efficient, general purpose,
industrial usage blast cabinets, designed for use with a wide range of abrasive
blasting media.
PanBlast™ PB1000 Cabinet Standard Features:
Commonly Used Abrasives:
* Cyclone type abrasive separator to clean the
abrasive while the system is in use
* Safety door interlock to prevent the blast system
from operating while the door is open
* Integral dry cartridge reverse pulse dust collector
to keep the cabinet ventilated and clear for the
operator
* Heavy duty wear resistant rubber gloves which
protect the operator and provide long wear life
* Quick change laminated glass viewing window
which requires no tools to replace
* Fully adjustable abrasive feed tee which allows
the system to operate on virtually any abrasive
media size and type
* Compressed air regulator and gauge to provide
for the blasting pressure to be varied for differing
applications
* High performance PanBlast™ Delta Suction Gun
to provide faster and more effective cleaning
* Standard air blow down gun to remove dust from
components after blasting
PanBlast™ PB1000 Cabinet Common Applications:
* De-scale and de-rust metal surfaces
* Remove paint and powder coating
* De-burr, de -flash and remove
sand from castings and moldings
* Provide decorative finishes to
stainless steel, aluminium and
other non-ferrous metals
* Etching of glass, stone and metals
* Removal of release agents and
contamination from molds
Commonly Used Abrasives:
* FastBlast™ Chilled Iron Grit
* PanaGrit™ Cast Steel Grit
* QuickCut™ Aluminium Oxide
* BrightBlast™ Glass Beads
* EnviroGrit™ Garnet
